Custom Wire Harness Assembly and Superior Customer Service
Our mission is to provide high-quality wire harness assemblies and services that help our customers gain a competitive advantage in their markets. We support this mission with an experienced employee team, the right equipment and a level of service that is unsurpassed. Whether filling scheduled orders or building a custom stocking program, we’re a partner you can rely on to help meet your production goals.
Since American Cable & Harness (ACH) was founded, we’ve provided unmatched expertise and quality combined with one-on-one personal service to deliver exactly what you need, when you need it.
Our highly trained technical staff treats every project as unique, because every project truly is. Whether you need 20,000 small wire harnesses for hair clippers or a short run of a critical component for a sophisticated medical device, you will receive a robust and reliable assembly.
Wire Harness Assemblies Built To Meet Exacting Standards
As a US-based contract manufacturer with facilities in Wisconsin and Iowa, we take pride in building high-quality, reliable interconnect solutions. Whether it’s 100 units or 100,000 units, for a large corporation or a small OEM, top quality is our goal, combined with superior service and value. We build to IPC-WHMA-A-620 Class II and Class III and UL 508A standards.
A custom wire harness is a bundled grouping of wires and/or cables that is installed into a larger product or device during the manufacturing process to create connections such as power or data within the product or device. Each wiring harness assembly project is unique in its length, quantity, complexity and application. No two custom wire harnesses are alike.
What Makes A Wire Harness Assembly Different From A Cable Assembly?
A wire harness organizes wires together while keeping them all visible and allowing individual wires to be removed if necessary. They’re usually installed in components of products or devices that are used in less challenging environments and applications and have an external hard shell for protection. Wire harness assemblies are also present in most automobiles and airplanes. A cable assembly is generally more durable and intended to withstand tough environmental hazards such as moisture, friction and heat. We can help you determine whether the assembly you need is called a wire harness assembly or a cable assembly. We manufacture both.
Custom Wire Harness Capabilities from Simple to Complex
Our capabilities allow us to meet the challenge of any length, any quantity and any level of complexity, from cut, strip and terminate to extremely complex wire harness assemblies with multiple breakouts. From 26 AWG to 250 MCM, we work with high-temperature rated wire, marine-grade wire, and many other specialty wires and cables. Your custom wire harnesses will be built to IPC-WHMA-A 620 standards.
Automated cutting & stripping of multi-conductor cable
Cutting, stripping & terminating of lead wires
Large harness capability (up to 50 feet)
Braiding
Looming
Ultrasonic welding
Potting
ROHS-compliant tin dipping
Inline hot stamping of alphanumeric characters
Semi-automated heat shrinking
Wire marking
Label wrapping
Automated pull testing
Continuity & functional testing of complete harnesses
Continuity & Functional Testing of Custom Wire Harness Assemblies
You can count on the functionality and reliability of your completed wire harness assemblies. Capabilities include:
CableEye Testing
Checks for opens, shorts and mis-wires
Measures diode forward voltage
Checks resistance values
Tests conduction and isolation resistance against specified thresholds
Automated Pull Testing (performed on all terminal crimps)
Ensures against under-crimping, which can pull off the wire and/or jacket
Ensures against over-crimping, which can damage the wire and the jacket
Your All-In-One Solution
We serve customers in many industries, such as industrial controls, scientific instrumentation, aerospace, medical, agriculture, water purification and monitoring, high-density mobile storage systems and HVACR building controls. Rigorous, reliable and responsive, we exceed expectations through continuous improvement, personalized service and ISO 9001:2015 quality management.
New Product Introduction (NPI) Process for Custom Wire Harness Assemblies
Bill of Materials
The customer provides a list of materials and requirements, which goes to our engineers for analysis.
Cut Sheet
Our engineers break down the bill of materials, fill in gaps, and organize it to allow our team to put together an NPI build. The cut sheet must be detailed in describing characteristics such as the type of wire, its gauge, its color, its length and how far back it should be stripped.
The NPI Build
New Product introduction
Our team lays out the custom wire harness and creates an engineering document, including details regarding looming, sleeving, braiding or tie-wrapping.
Markup
By examining and testing the NPI build, we determine what must be changed and capture that information in Engineering Change Notices. The bends, breakouts and multiple terminals involved can mean that wires need to be longer or shorter, or the amount they are stripped back must be changed. Continuity testing assures our customers that the routing of the wire matches from end to end.
Production
After changes and testing are complete and the customer has signed off, we proceed to the production build.
Custom Wiring Harness Industries & Applications
Many everyday household products and tools incorporate wire harness assemblies. Here are just a few of the applications and industries representing our experience as a wire harness assembly manufacturer, from lighting inside private jets, to leaf blowers and sheep shears, to custom wire harnesses for medical and dental equipment.
